Light Oil Burners

Technical Specification:

  • Optimal fuel / air mixture with special oil head,
  • Compact design and low noise levels,
  • Single –Stage & Two-stage operation,
  • Flame control with Photocell.
  • Hinge facility for easy maintenance.
  • Easy access to all equipment without disassembling the burner,
  • Control of the combustion air with the air pressure switch,
  • Easy installation and operation
BURNER
MODEL		 HEAT OUTPUT
(Kcal / Hr) 		HEAT OUTPUT
(kW) 		LIGHT OIL
CONSUMPTION (Ltr/Hr)		 MOTOR
(Hp)		 VOLTAGE
(Ph) 		FLAME LEGTH
(Mtr) 		FLAME DIA
(Mtr) 		OIL PUMP
(kW)		 BACK PRESSURE
  Min. Max. Min. Max. Min. Max.     Min. Max. Min. Max.   Graph
NLM 50 8,600 43,000 10 50 0.91 4.53 0.25 1 0.14 0.32 0.08 0.14 0.25
NLM 100 17,200 86,000 20 100 1.83 9.05 0.25 1 0.28 0.63 0.17 0.29 0.25
NLM 150 25,800 129,000 30 150 2.74 13.58 0.25 1 0.35 0.77 0.19 0.33 0.25
NLM 220 34,400 189,200 40 220 3.66 19.92 0.5 1 0.40 0.94 0.21 0.38 0.25
NLM 300 43,000 258,000 50 300 4.57 27.16 0.5 1 0.53 1.10 0.26 0.42 0.25
NLM 500 86,000 430,000 100 500 8.78 43.88 1.00 3 0.63 1.41 0.29 0.49 0.25
NLM 700 116,100 580,500 135 675 11.85 59.23 1.00 3 0.73 1.64 0.32 0.55 0.25
NLM 900 159,100 786,900 185 915 16.23 80.30 2.00 3 0.86 1.91 0.36 0.61 0.50
NLM 1400 236,500 1,161,000 275 1350 24.13 118.47 2.00 3 1.05 2.32 0.40 0.69 0.50
NLM 1800 313,900 1,591,000 365 1850 32.03 162.35 3.00 3 1.20 2.72 0.45 0.77 1.00
NLM 2700 473,000 2,365,000 550 2750 48.27 241.33 3.00 3 1.48 3.31 0.51 0.88 1.00
NLM 4250 774,000 3,655,000 900 4250 81.47 384.74 7.00 3 1.84 4.15 0.59 1.02 1.00
NLM 5500 1,032,000 4,730,000 1200 5500 108.63 497.89 10.00 3 2.10 4.69 0.65 1.10 1.00
NLM 6500 1,204,000 5,848,000 1400 6800 126.74 615.58 12.00 3 2.28 5.25 0.68 1.19 2.00
NLM 7500 1,376,000 6,536,000 1600 7600 144.84 688.00 15.00 3 2.41 5.59 0.71 1.24 2.00
NLM 9500 1,462,000 8,170,000 1700 9500 153.89 860.00 20.00 3 2.53 6.29 0.73 1.35 2.00
